Capacities up to 1,250 lbs per caster - Wheel Sizes Ranging from 4" to 8" Diameters
Plate Size: 4" x 4-1/2"
This series class is one of Caster HQ's most recognized and commonly used casters in a broad spectrum of industries and is one of our most popular selling caster series; offering exceptional quality, functionality, value, and availability! To offer fast delivery and competitive prices, we mass produce and stock all the parts required to quickly assemble these high-quality casters to your desired specifications. This series is made from 1/4” thick cold rolled steel; designed, formed, and welded for optimal mobility and made to withstand the rigors and abuses typical for medium-duty caster applications. Double ball raceways and a 5/8” nut & bolt kingpin are standard features; however we also offer a rivet kingpin version as well.
Popular applications include; various carts, trucks, dollies, racks & equipment for almost every industry including industrial, warehousing, hospitality, institutional, food service, food processing, retail displays, and endless other medium-duty applications.Caster Features: • Double ball raceways offer smooth swiveling action and heat treatment for added strength and longer service life. • Economically priced for OEM high-volume usage. • Standard 5/8” nut & bolt kingpin • Zinc plated finish is attractive & corrosion-resistant. • Zerk grease fitting in raceway & axle for maintenance. • Majority of series and wheel types are NSF Listed. • Standard stock series = Quick Deliveries Questions? Please Call us @ 844-439-4335 or Contact Us Here
For quick online service please email us at info@casterhq.com and a Caster Expert will help you answer any questions.
We ship Fast!!! If ordered before 12 noon we ship all orders typically ship SAME DAY! All orders received after 12 noon will ship the following business day!
Want to protect your walls and equipment?
A great add-on for your carts or equipment is our corner bumpers. Corner bumpers are designed to install on any piece of equipment or cart that could potentially damage walls and to child-proof sharp corners to prevent potential damage to children or animals caused by sharp corners. Our Gray 1" Thick by 3" long sides corner bumpers are non-marking and steel reinforced. CasterHQ's gray corner bumpers must be drilled into your equipment using 5/16" screws. Each Corner Protector has two holes on each side, totaling four holes per bumper. This corner bumper is commonly added to carts to prevent wall damage while rolling through hallways, hospitals, cruise ships, or tight spaces. The corner bumper will help prevent the corner of the cart from damaging walls or scratching areas that need protection. This is a fantastic upgrade to any cart, platform truck, or equipment as a precautionary method for protecting walls. Some customers will use these corner bumpers on their tables, countertops, and household items to prevent toddlers from accidentally bumping their heads on potentially hazardous home areas to protect the little ones from getting hurt. There are numerous applications for corner bumpers. Add them to your order for added protection.
These work with any Swivel Casters found on this page with a 4" x 4-1/2" Top Plate. This will allow you to convert your swivel caster into a rigid caster when you need straight-line tracking and easily convert the casters back to swivel in close quarters.
